Axitec 320W Poly Solar Panel - AC-320P/156-60S |
Axitec, 320W Poly Solar Panel, 60 Cell, 1000VDC, 15A, Plug-In System, AC-320P/156-60S The polycrystalline modules of the AXIpower series are the all-purpose choice among solar modules. Whether for rooftop or ground-mount installations, AXIpower modules with an effi ciency of up to 15.98 % provide an outstanding energy yield and a great return on investment. As a pioneer in solar, AXITEC dedicates itself to implementing the newest advances in manufacturing of solar modules. Through long-term relationships in the industry, AXITEC has become one of the technological and economical leading manufacturers in solar. All productions are subject to strict quality standards and are continuously monitored by neutral testing laboratories. Over the last 14 years, thousands of homeowners and businesses have put their trust in AXITEC and invested in their future. This is AXITEC’s commitment to the future of energy. |
Features
|
General Information | |
Manufacturer: | Axitec |
Product Line: |
AXIpower |
Model ID: |
AC-320P/156-60S |
Certifications and Safety Ratings: | ![]() ![]() ![]() |
Mechanical Data |
|
Technology: | Polycrystalline (Poly) |
Dimensions: |
77.01 x 39.06 x 1.57 inches (AC-320P/156-60S Dimensions) |
Weight: | 50.70 lbs |
Frontside: | 0.13 Inch (3.2 mm) Hardened, Low-Reflection White Glass |
Cells: | 72 Polycrystalline High Efficiency Cells 6 Inch (156 x 156 mm) |
Backside: | Composite Film |
Frame: | 1.57 Inch (40 mm) Silver Anodized Aluminum Frame |
Socket: | Protection Class IP67 (3 Bypass Diodes) |
Wire: | 43.3 Inch, AWG 11 |
Plug-In System: | Plug / Socket IP67 |
System Voltage: | 1000 VDC (UL), 1000 VDC (IEC) |
NOCT (Nominal Operating Cell Temperature): | 45°C +/-2K |
Maximum Load-Carrying Capacity: | 50 PSF |
Reverse Current Feed IR: | 15.0 Amps |
Permissible Operating Temperature: | -40°C to +85°C |
Electrical Data |
|
Nominal Output (Pmpp): | 320 Wp |
Nominal Voltage (Umpp): | 37.39 Volts |
Nominal Current (Impp): | 8.58 Amps |
Short Circuit Current (Isc): | 9.18 Amps |
Open Circuit Voltage (Uoc): |
45.59 Volts |
Module Conversion Efficiency: | 16.49% |
Voltage Uoc: | -0.30%/K |
Current Isc: | 0.04%/K |
Output Pmpp: | -0.42%/K |
Datasheets |
|
Document | Type |
![]() |
Specifications |
![]() |
Installation Guide |
![]() |
Brochure |
Warranty | 15 Year Manufacturer's Guarantee on 90% of Nominal Performance |
Performance Guarantee | 25 Year Manufacturer's Guarantee on 85% of Nominal Performance |
![]() |
